RÄF-90 M
End bracket
Categories RÄF end fasteners[+]
Cable trays / KRB / Accessories / RÄF end fasteners
Cable trays / KRA / Accessories / RÄF end fasteners
[-]
Cable trays / KRB / Accessories / RÄF end fasteners
Cable trays / KRA / Accessories / RÄF end fasteners
[-]
End brackets RÄF are used for mounting the ends of KR-type cable trays to wall, floor or ceiling. For fastening one end of cable tray two brackets RÄF are needed.
Product set includes bolt and nut for fastening bracket to cable tray.
Product Attributes
Dimension Data
Video
BIM
Product Attributes
Product Name
RÄF-90 M
SKU
1432735
Color
White
Material
Steel
Surface Finish
White RAL 9010 polyester paint coating
GTIN Code
6438377016500
Corrosion Category
C1-C2
Fire Resistance
Loading Capacity kg
Sales Unit
PCE
Packing Size
10 PCE
Carbon Footprint kg/PCE
0.421
Stock Status
Not in Stock
Dimension Data
Length (mm)
80
Width (mm)
45
Height (mm)
87
Dimension L (mm)
Dimension A (mm)
87
Dimension B (mm)
Dimension C (mm)
Dimension D (mm)
Dimension E(mm)
Dimension F (mm)
Dimension G (mm)
Dimension H (mm)
87
Material thickness (mm)
2
Weight kg/PCE
0.16
Video
BIM
Meka’s product range is available in friendly and ready-to-be-used 2D-, 3D-, and Revit models.
Please contact technicalsupport@meka.eu to receive:
- 2D model of the product in DWG format
- 3D model of the product in STP format
- Autodesk™ Revit model
For your need to work on product models without a separate download, please request access to the Aveva™ E3D Design software.
